New Telescopic Leg Assembly

April 12, 2007
Monarch Hydraulics, Dyna-Lift Division would like to introduce its brand new TELESCOPIC LEG ASSEMBLY. The new TELESCOPIC LEG ASSEMBLY is available for OEM height adjustable applications, featuring two columns with either manual (hand crank) or electric actuation. Lifting capacities of 250lbs. per column or 500lbs. per set. Multiple columns are also available. The new TELESCOPIC LEG ASSEMBLY is easy-to-install. Simply secure your top and bottom frame with (4) 5/16”self tapping screws to the columns then just add your table top. The columns quickly transform into a perfect workstation best suited for office, medical, and light industrial environments. The new TELESCOPIC LEG ASSEMBLY is now available for OEM applications seeking optimum height adjustable positioning regardless of off-center or cantilever loads. Monarch Hydraulics provides the right ergonomic solution for all your height adjustable needs with system lifting capacities from 250 lbs. to 20,000 lbs. and all load capacities in between. Kits are available for easy mounting to existing equipment or original equipment designs. Made in the USA by an ISO 9001 Registered facility. • Materials: extruded aluminum with clear matte anodized finish • Adjustment range: o 12" (305 mm) o 24" (610 mm) full retracted o 36" (914 mm) fully extended • Capacity: 250 lbs per column and 500 lbs per set of 2 columns • Multiple columns available • Designed to be used with B1C cylinders • Manual (hand crank) or electric actuation
