V36G Series Soldering Stations Come in 20, 40 and 60 W

April 29, 2008

A line of industrial-grade soldering stations that combine high thermal capacity with adjustable tip temperatures to optimize joint quality, the V36G Series Soldering Stations are compact, bench-top units with detachable stands and dross collection sponges that provide adjustable tip temperatures from 175 to 1,100°F.


Featuring Ni-chrome compression wound heating elements, 100% encased in steel, and iron-clad copper tips to ensure long life with optimal heat transfer, they provide quick recovery times for soldering multiple joints and overcoming high heat sinking properties. Permitting the higher temperatures required by lead-free solders and lower temperatures to save energy during work breaks, American Beauty V36G Series Soldering Stations provide adjustability based upon a percentage of output.


Models with 20, 40, and 60 W power and 1/8, 3/16, and 1/4 in. dia. tips, respectively, are available with chisel, diamond, and conical tip shapes.

 V36GS3V36GM3V36GL3 Standard Tip StyleChisel, Diamond, Conical Wattage20 W40 W60 W Max. Temp. 800°F (427°C)  950°F (510°C)  1,050°F (566°C)  StandYes Available in a 220 to 240V AC?No Tip Diameter0.125 in.0.1875 in.0.25 in. Harmonization Code8515.11.0000 RoHS CompliantYes IEC 60335-1, Edition 5.1, 2013-12Yes IEC 60335-2-45, Edition 3.2, 2012-01 Yes WEEE CompliantYes CE CertifiedYes
