UPS, 850VA, 510 Watts, 230 Volt, Din Rail Mount

Jan. 31, 2014
The SDU Off-Line DIN Rail UPS Series provides industry leading compact design with a wide operation temperature range and an installation option not easily found with competing products. The DIN Rail UPS provides economical protection from damaging impulses and power interruptions. These units include accessible connection screw terminations for critical devices needing battery back-up such as computer based control systems.Features:
  • Lightweight, Compact Industrial Design — Only 4.88" × 11.1" × 4.55" and Less Than 12 Lbs.
  • DIN Rail Mounted with Easy-to-Wire Screw Terminations
  • Software and Cable Included
  • Hardwired Input/Output Connections with IP20 Touch Proof Screw Terminals
  • Phone Line Surge Protection Included
  • RS232 Communication Port Included, USB Port Optional
  • Simulated Sine Wave Output
  • 120 V Models Are UL 1778 cRUus Recognized for Industrial Applications without Derating
  • No Derating Required in UL 508 Applications
  • Two-Year Warranty

    Applications:
  • PLCs
  • Factory Automation
  • Robotics
  • Conveying Equipment
  • Computer-Based Control System
  • Time, Backup:2.5 | IP Rating:IP20 | Output Type:24-10 AWG Wire, Screw Terminals | Brand/Series:SDU Series | Capacity:850 | Dimensions:124 H × 281 W × 116 D | Type:Industrial | Input Type:24-10 AWG Wire, Screw Terminals | Communication:RS232 | Voltage, Output:230 | Mounting Type:DIN Rail | Power, Rating:510 | Weight:5.4 |
