Explosion Proof Fluorescent Lights for Paint Spray Booths - Larson Electronics LLC
This fixture is a 2 foot long, 2 lamp, UL listed Class 1 Division 1 and Class 2 Division 1 & 2 explosion proof fluorescent light and an ideal choice for use in applications where space is at a premium. This T6 temperature rated fixture comes standard with F24-T5/HO lamps and is available with a variety of lamp options including; T12HO, T8, T5, T12DLHO, and B40. The lamps are protected by heat and impact resistant Pyrex tubes and the fixture is constructed of copper free aluminum alloy.
U.L. Listing: United States – Canada U.L. Ratings
Total Watts: 48 *Standard T5HO Class 1 Division 1, Groups C,D
Total Lumens: 4,000 *Standard T5HO Class 1 Division 2, Groups A,B,C,D
Voltage: Multi – 120V-60Hz, 220V-50Hz, 240V-60Hz, Class 2 Division 1-2, Groups E,F,G
277V-60Hz UL 595 Outdoor Marin Type (Saltwater)
Lamp Life Expectancy: 20,000+ Hours *Standard T5HO UL 1598 Marine Type
Color Temp: Varies with Bulb Choice UL 844, 924
Mounting: Bracket Standard – Pendant Optional California Title 24 Compliant
Wiring Hub: ½ inch threaded UL Listed for Paint Spray Booths
Operating Temp Rating: T6 Rated
Bulb Type: T12HO, T8, T5, T12DL, or B40
Contact us for special requirements
