Compact 7 Watt LED Fixture for Hazardous Area Locations

June 30, 2014

This low voltage hazardous area lighting solution is approved for Class 1 Division 2 environments and 1598 compliant for use in wet locations. This powerful LED light produces 587 lumens, operates from 12 to 24V DC, and is available in a variety of configurations to allow tailoring to the specific requirements of various applications. This light is constructed of precision machined aluminum for excellent strength and durability. This unit is rated IP66 for ingress protection against dust and direct exposure to high pressure water spray.

Lamp Type: LED Ratings/Approvals

Watts: 7.9 @ 12V DC & 8.4W @ 24V DC Class 1 Division 2, Groups A,B,C & D

Lumens: Spot-587 or Flood-459 CSA 22.2 No. 250.0

Beam Type: 30° Spot or 100° Flood UL 1598

Operating Temp Rating: T3 Rated IP66 Ingress Protection

Lamp Life Expectancy: 100,000 Hours

Mounting: ¼” – 20 Screws/Aluminum Yoke

Voltage: 12-24V DC

Wiring: 6ft Lead ? White: + Black: -
