Maintaining A Clear Perspective: 5 Tips for Wipers

Aug. 11, 2020
Easily forgotten, wipers play a critical role in keeping your trucks safe.

Your drivers have probably all experienced that moment of panic while driving in traffic: Clear day, dry roads; then suddenly a storm out of nowhere. The heavens open and it starts to rain. Hard. So hard, the windshield has been overwhelmed by a wall of water and they are blinded and the panic sets in.

It’s at times like these that wipers become their biggest ally. When they reach down to turn them on they expect them to clear all that water in a matter of seconds, praying that they won’t rear-end the vehicle ahead. This is why having well-maintained wipers is so critical to safety and could even impact your fleet safety record.

Wiper reliability is no accident. They’ve been around as long as trucks first started plying highways over a hundred years ago. There have been many refinements since to make them more efficient—better blade material, larger coverage, even automatic sensing to engage automatically, and adjust speed to rain/spray volume.

Ultimately, the most important component for reliability is the motor. If it fails or underperforms, all the improvements to the rest of the system don’t matter. Unfortunately, not all motors are the same. Because there are so many of them out there, it has become a commodity and many are built as cheaply as possible.

Ideally, motors and wiper systems are built to suit the vehicle type. A well-designed system has the right gearing and motor rating to ensure it isn’t overtaxed by the size of the wipers. If you are having a lot of early failures of motors or wiper components, it could be a result of a poor specification. That’s why our engineers spend a lot of time with vehicle manufacturers getting this specification right.

But proper wiper system maintenance shouldn’t be neglected. Research has shown that poor visibility is a significant contributor to many accidents. If one of your trucks was involved in one of these accidents, your wiper maintenance records could be under scrutiny and you could be liable if wiper operation was a factor in the accident.

To ensure wiper reliability and reduce accident risk in wet and wintry driving conditions, here are five key things to focus on:

1. Have A Regular Testing Protocol

When trucks are in the shop for regularly scheduled maintenance, make sure wipers are checked and tested. This should include an inspection of blades for cuts or damage and running the wipers at each speed. Replace any damaged components. Also ask drivers to be proactive about reporting any issues they are having with wiper operation or poor visibility. If you are having repeated problems with some systems, consider retrofitting with a more reliable wiper motor/arm assembly suited to the vehicle and its windshield design.

2. Optimize Windshield Coverage

For best visibility, it’s important to maximize the windshield area the wipers will cover. When wipers are initially specified, engineers consider a number of factors:

  • The breakaway curve, or the place where the curve of windshield glass becomes too great to wipe.
  • The daylight opening (DLO), which is the total area of the windshield glass that you can see through from the inside edges of the molding.
  • Whether to use a pantograph (where the wiper blade stays parallel to the side of the glass) or radial (arced sweep pattern) type. A radial wipe pattern is best when your glass is wider than it is tall, which is the most common. A pantograph pattern works better on tall, narrow glass.

Ideally, the wiper length and sweep pattern covers as much of the daylight opening as possible when factoring in the curvature of the glass and the amount of breakaway curve you are dealing with. If the standard wipers on your trucks are not providing good coverage, you should consider retrofitting with systems that increase it.

3. Specify The Right Blades

Wiper blades come in a wide range of styles and compounds. Just like tires, which come in different compounds, the softer the compound, the faster the wear. You need to balance the need for a good “clean” with softer compounds with the longer life of a harder compound. If you operate in colder parts of the country, consider using different blades during the winter which are better able to handle snow, sleet, and ice. At the end of winter, consider replacing with blades more suited to rain-only events.

4. Make Sure You Have Adequate Circuit Protection

Wiper motors will draw more power under load when driving in heavy snow or windy conditions. To avoid premature circuit breaks, use the right breakers. 12 V DC motors draw about 5 amperes during normal use. We recommend you use a 10 amp circuit breaker for one 12 V DC motor, or a 15 amp circuit breaker for a two-motor system. For 24 V DC motors, use a 5 amp breaker for one motor and a 7 amp breaker for two.

5. Specify Motors Which Suit The Application

Wiper motors are rated by stall torque. This is usually expressed in Newton-meters (Nm). It’s important you have motors that have the torque to handle the type of wiper application. Here’s our recommendations:

  • A 38 Nm motor is recommended for arm and blade combinations of 28” (710 mm) and longer and for multiple arms and blades driven by one motor.
  • A 30 Nm motor is suitable for arms and blades in the 20” to 28” (500 mm to 710 mm) range.
  • A 12 Nm motor is appropriate for arms and blades in the 16” to 20” (400 mm to 500 mm) range.
  • An 8 Nm motor works well for small arm and blade combinations of 16” (400 mm) and under.

Note that motors of 20 Nm or less often have an internal linkage to make the necessary oscillating motion.

Good maintenance and specification of wiper systems serve the dual purpose of reducing accident risk and keeping drivers happy. Both of these go straight to your company’s bottom line. Which should make it a high priority in your operation.


Author: Will Watson, AM Equipment
