Permanent Magnet DC Motors

April 5, 2012

The Permanent Magnet DC Motor line features NEMA frames 48, 56, and 180 with an output range 1/8 to 4 HP, 500 to 4,000 RPM and 12 to 128 VDC. They are specified for a broad range of applications including, fork lifts, scissor lifts, electric vehicles, floor care appliances, amusement rides, robots, pump drives, blower drives, reels, winches, railroad track switchers, crossing gates, office equipment and medical instruments.

Other features include long life sealed ball bearings with high temperature grease, low loss steel laminations, NEMA-rated magnet wire, high efficiency, high startup torque, precision dynamic balancing, external brush access, power off dynamic braking, excellent heat dissipation, high temperature polyester varnish impregnated armatures, easily reversible, and UL/CSA Listed. Options include motor temperature sensors, motor brush wear indicators, sensor bearings, anti rust zinc coating, rectified designs with power cord set for AC power, skewed stack design for low cogging and private labeling.

  • NEMA frames 48, 56, and 180
  • 500 to 4,000 RPM
  • 12 to 128 V DC
