20 A, 125 to 250 VAC, FootswitchThe rugged, long life “Clipper” maintained models offer a push-on, push-off operation with long, trouble-free performance. Models 632-DA and 632-S consist of a cast-iron housing with skidproof base pads, black finish and strain relief connector. Model 632-S Twin consists of two SPDT switches, on a heavy steel base. Dimensions:632-DA and 632-S — 41?2" × 31?2" × 11?2"; 632-S Twin — 83?8" × 41?2" × 11?2". Weight: 632-DA and 632-S — 21?4 lbs.; 632-S Twin — 5 lbs.632-DA, 632-S, and 632-S Twin
Rated: 20 A, 1 HP @ 125-250 VAC
632-SC3, and 632-DC3A Rated: 15 A, 3?4 HP @ 125 VAC Color: Black | IP Rating: IP20 | Number of Positions: 2 | Material: Cast Iron (Housing) | Operation: Momentary | Voltage, Rating: 250VAC | Mounting Hole Size: 5.56mm | Number of Poles: 1 | Type: Foot | Weight: 2-1?4 lbs. | Contact Form: SPDT-NC/NO | Current, Rating: 20A | Standards: UL Listed, CSA Certified, CE Marked |
632-SC3, and 632-DC3A
