Relay;SSR;Timing;On Delay;DPDT;Cur-Rtg 5, 0.15A;Ctrl-V 24-48/12-48AC/DC;11 Pin

H3CR Series. Field-selectable time ranges (0.05 sec. to 300 hrs. or 0.01 sec. to 600 hrs.). Choice of 6 (11-pin) or 4 (8-pin) function models. New PNP voltage input available. SPDT or DPDT time limit contact output. New universal supply voltage (100-240 VAC/100-125 VDC or 24-48 VAC/12-48 VDC). Features:

Multi-Function Models Available in 4 or 6 Functions

Timing Functions: 4 Function: ON-delay, Repeat Cycle ON, Interval, One-Shot (8-Pin)

6 Function: ON-Delay, Repeat Cycle ON or OFF, Signal ON/OFF, Signal OFF, Interval (11-Pin)

Repeat Cycle Models with Independent ON and OFF Periods

Short 80 mm (3.15 Inch) Panel Depth with Socket

Field Selectable Time Ranges from Front Panel

UL, CSA, CE Approved Specifications:

Supply Voltage: Multi-Function: 00-240 VAC/100-125 VDC or 24-48 VAC/12-24 VDC, Repeat Cycle: 100-240 VAC or 24 VAC/VDC

Timing Ranges: Multi-Function: 0.05 Sec. to 300 Hrs., Repeat Cycle: 0.05 Sec. to 30 Hrs.

Repeat Accuracy: Multi-Function: +±0.2% of Full Scale Max, Repeat Cycle: ±0.3% of Full Scale

Control Output: DPDT — 5 A @ 240 VAC/30 VDC, DPDT — 5 A @ 250 VAC (H3CR-F Models)

Contact Form:DPDT | Standards:UL, CSA, CE | Voltage, Rating:250?125 | Mounting Type:DIN Rail?SMD | Current, Rating:5 | Relay Type:Solid State | Temperature, Operating, Maximum:55 | Number of Pins:11 | Timer Type:On Delay | Function:Timing | Temperature, Operating, Minimum:-10 | Voltage, Control:48 | Timing Range:0.05 sec. to 300 hrs. |
