BlueWave MX-150 LED Spot-Curing System

Aug. 11, 2016

BlueWave MX-150 is a unique, smaller LED spot-curing system with unique curing flexibility. The system can be used as a bench-top unit or integrated into an automated system, and its LED emitters are available in 365, 385 or 405-nm wavelengths. In addition to providing great curing flexibility, the BlueWave MX-150 is also designed to offer higher, more consistent curing intensities than traditional spot-curing systems.

Output frequencyRediCure: 365 nm PrimeCure: 385 nm VisiCure: 405 nmIntensity output*RediCure: 24 W/cm² PrimeCure: 38 W/cm² VisiCure: 36 W/cm²Power supply input100-240V? 2.5A, 50-60HzLED timer0 to 999 secondsLED activationFoot pedal, LCD touch screen, or PLCCoolingAir CooledDimensions (W x D x H)Controller: 5.14 x 7.19 x 7.35 in. (13.1 x 18.3 x 18.7 cm) Emitter: 7.9 x 1.97 x 1.97 in. (20.06 x 5 x 5 cm)WeightController: 2.6 lb. (1.18 kg) / Emitter: 1.4 lb. (0.64 kg)Unit warranty1 year from purchase dateOperating environment10 to 40°C, 0 to 80% non-condensing*Measured using a Dymax ACCU-CAL 50-LED Radiometer at a distance of 0 mm.
  • High Intensity of up to 40 W/cm²
  • Quickly cures a variety of materials
  • LED emitters for 365, 385 or 405 nm wavelengths
  • Cures LED-optimized and UV/Visible-light curable materials
  • Wavelength flexibility allows co-optimization of adhesive and cure system for optimal cure
  • LED chip located in the emitter, not the controller
  • Consistent intensity
  • Mounted emitter saves the cost of lightguides
  • Eliminates potential intensity loss from long or bent lightguides
  • Easily mounted to robotic arms with no intensity variation
  • Emitter can be mounted closer to application, while the controller remains close to the operator
  • Admin and production sides
  • Production mode for simple on/off operation
  • Curing programs can be easily entered, stored, and recalled when needed
  • Units can be password protected so only the Production Mode can be accessed by workers
  • Touch screen with full keyboard
  • Improved user interface
  • Compatible with 3 and 5-mm lightguides with Wolf Connector
  • Utilizes standard/readily available lightguides
  • Instant on/off
  • No warm-up period
  • More energy efficient
  • Efficient LED temperature management and system monitoring
  • Maximized continuous operation without overheating
  • Comfortable hand-held operating temperature
  • Temperature monitoring assures maximum LED life
  • Checks presence of lightguide or other delivery optic
  • PLC interface for easy inclusion in automated systems
